Melt gear pump core technology principle

Melt gear pump belongs to external gear pump, its working principle is based on the gear meshing movement to realize the melt transport and measurement, is currently more widely used a pump, its working process is mainly as follows:

1, inhalation process: when the active gear and the driven gear in the motor drive in a certain direction of rotation, the teeth of the two gears in the suction chamber gradually disengaged meshing, so that the volume of the suction chamber increases, forming a local vacuum. Under the action of atmospheric pressure, the melt is sucked into the suction chamber and filled in the groove of the gear teeth.

polymer melt gear pump

2, conveying process: as the gear continues to rotate, inhaled into the groove of the melt by the teeth of the wheel to the discharge chamber. In this process, due to the meshing effect of the gears, the melt in the tooth groove is forced forward, like a spoon to scoop up water, the volume of melt carried by each tooth groove is basically fixed, so the melt pump can also be used for metering.

3, discharge process: when the gear teeth into the discharge chamber, the teeth gradually meshed, so that the melt in the tooth groove is squeezed, the volume of the discharge chamber decreases, the melt pressure rises, so that the melt from the discharge chamber discharged to the pump's outlet pipeline, transported to the next link.

In the whole working process, the melt gear pump can transport the melt stably, efficiently and accurately through the precise meshing and rotation of the gears. Moreover, the melt pump is generally equipped with a frequency conversion gear motor, which can control the flow of the melt by adjusting the rotational speed to meet the needs of different production processes.

melt pump for extruder

Since its establishment in 2006, Zhengzhou Batte has been specializing in the research and development of melt pumps, melt gear pumps and related products, and has been deeply cultivating in the industry for twenty years. The company has a large gear pump production base of nearly 5,000 square meters. In the spacious and modernized plant, all kinds of advanced production equipment are arranged in an orderly and efficient operation. From precision machine tools to intelligent testing instruments, everything is available to ensure the manufacturing precision and quality of each melt pump.
