batte melt pump

PET packaging belt dedicated metering melt pump

Thermoplastic melt metering pumps can be used in various extrusion industries, such as sheet, sheet, pipe, film, granulation, wire drawing, cable, co extrusion, mixing, precision extrusion, and other industries.

thermoplastic extrusion pump

Advantages of special metering melt pump for packaging belt

1. Minimal pressure and flow pulsation can achieve linear output of flow, suitable for precision extrusion systems;

2. Adopting different structures and material configurations for different working conditions to better meet the personalized needs of users;

3. It can be applied to high temperature (350 ℃), high pressure (40MPa), and high viscosity (40000 Pa • s) working conditions;

4. Precision structure, high precision, and long service life.

thermoplastic hot melt pump

Technical parameters of packaging belt thermoplastic extrusion pump

Transmission medium viscosity: 1-40000Pa • s

Suction pressure: 0-30MPa

Output pressure: 0-40MPa

Allowable pressure difference: 25MPa

Operating temperature: ≤ 350 ℃

Heating method: electric heating

melt pump manufacturer

The flow rate of the thermoplastic hot melt pumps is related to the working speed, material viscosity, and working pressure. Please consult the manufacturer for specific selection. The selection needs to provide parameters: 1. Flow rate or output; 2. Material name; 3. Material viscosity; 4. Corrosiveness/toxicity of materials; 5. Inlet and outlet pressure (pressure difference); 6. Operating temperature.
