batte melt pump

Special metering pump for thermoplastic extruder

The ZB-B series extruder dedicated metering pump is a universal metering pump used in electric heating extrusion systems. Suitable for extrusion and transportation of polymer melts from low viscosity to extremely high viscosity; Generally installed between the outlet of the extruder and the die head, used as a thermoplastic melt pump; It can also be installed in polymer melt pipelines for use as a booster pump. It is widely used in various extrusion industries, such as sheet, sheet, pipe, film, granulation, wire drawing, cable, co extrusion, mixing, precision extrusion, etc.

thermoplastic melt pump
thermoplastic melt pump

Technical parameters of dedicated melt pump for plastic extrusion

Transmission medium viscosity: 1-40000Pa • s

Suction pressure: 0-30MPa

Output pressure: 0-40MPa

Allowable pressure difference: 25MPa

Operating temperature: ≤ 350 ℃

Heating method: electric heating

melt pump for plastic extrusion
melt pump for plastic extrusion

Characteristics of Special melt gear pump

1. Universal and economical melt pumps.

2. It is also suitable for low viscosity and low vacuum conditions.

3. Can be used for boosting or metering.

4. Multiple sealing methods available.

5. Electric heating is suitable.

melt gear pump
melt gear pump

Selection of polymer melt gear pump

The flow rate of the extruder melt metering pump is related to the working speed, material viscosity, and working pressure. Please consult the manufacturer for specific selection. The selection of melt metering pumps requires the following parameters:

1. Flow rate or output;

2. Material name;

3. Material viscosity;

4. Corrosiveness/toxicity of materials;

5. Inlet and outlet pressure (pressure difference);

6. Operating temperature.

hot melt gear pump
polymer melt gear pump
